Cisco switch SF300-24 Switch

Cisco Small Business and Linksys

سوئیچ سیسکو - اس اف 300 - 24 پورت

این سوئیچ به عنوان یک سوئیچ small business شناخته می شود و در کسب و کارهای کوچک استفاده می شود.

پرسش و پاسخ

دانلود کاتالوگ

کانفیگ

سوئیچ سیسکو Cisco SF300-24P دارای 24 پورت 10/100و 2 پورت گیگابایت و 2 پورت combo mini-GBIC می باشد. این سوئیچ به عنوان یک سوئیچ small business شناخته می شود و در کسب و کارهای کوچک استفاده می شود.

24 10/100 ports, 2 10/100/1000 ports - 2 combo mini-GBIC ports	Product Description
24 x 10/100 + 2 x combo Gigabit SFP + 2 x 10/100/1000	Ports
N/A	Power Over Ethernet (PoE)
Switching capacity : 12.8 Gbps ¦ Forwarding performance (64-byte packet size) : 9.52 Mpps	Performance
16K entries	MAC Address Table Size
4K Active VLANs	Capacity
Static IPv4 routing	Routing Protocol

مشخصات سوئیچ Cisco SF300-24

SF300-24	Product Number
24 10/100 ports, 2 10/100/1000 ports - 2 combo mini-GBIC ports	Product Description
Switch - 24 ports - L3 - managed	Device Type
Desktop, rack-mountable - 1U	Enclosure Type
24 x 10/100 + 2 x combo Gigabit SFP + 2 x 10/100/1000	Ports
N/A	Power Over Ethernet (PoE)
Switching capacity : 12.8 Gbps ¦ Forwarding performance (64-byte packet size) : 9.52 Mpps	Performance
16K entries	MAC Address Table Size
4K Active VLANs	Capacity
Static IPv4 routing	Routing Protocol
SNMP 1, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI	Remote Management Protocol
10KB	Jumbo Frame Support
Secure Shell (SSH), RADIUS, TACACS+	Authentication Method
Layer 3 switching, layer 2 switching, DHCP support, BOOTP support, VLAN support, IGMP snooping, Syslog support, DoS attack prevention, port mirroring, DiffServ support, Weighted Round Robin (WRR) queuing, Broadcast Storm Control, IPv6 support, Multicast Storm Control, Unicast Storm Control, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, Quality of Service (QoS), Jumbo Frames support, MLD snooping, fanless	Features
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s	Compliant Standards
128 MB	RAM
16 MB flash	Flash Memory
Link activity, port transmission speed, system	Status Indicators
---------------------------	Expansion / Connectivity
24 x 10Base-T/100Base-TX - RJ-45 ¦ 1 x console - 9 pin D-Sub (DB-9) - management ¦ 4 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 2 x SFP (mini-GBIC)	Interfaces
------------------------------	Power
Power adapter - external	Power Device
AC 120/230 V ( 50/60 Hz )	Voltage Required
17.3 in	Width
10.1 in	Depth
1.5 in	Height
6.8 lbs	Weight
1 x serial cable	Cables Included
Included	Rack Mounting Kit
282,775 hour(s)	MTBF
UL 60950, FCC Part 15 A, CSA 22.2	Compliant Standards
-----------------------	Localization
32 °F	Min Operating Temperature
104 °F	Max Operating Temperature
10 - 90% (non-condensing)	Humidity Range Operating
-4 °F	Min Storage Temperature
158 °F	Max Storage Temperature
10 - 90% (non-condensing)	Humidity Range Storage
